Features：
- IC/RFID/Magnetic card read/write
- Support power-down eject card,PSAM options
- Dust and foreign object resistance bezel design
- Compatible with various communication protocols
- Modular design for easy maintenance
Description:
MR8 mainly composite plastic with high temperature, abrasion and aging resistance, and two sides of card movement channel are embedded with stainless steel metal. It makes product with advancement in strength and precision. Module installation structure is convenient for customers to maintain product. Elaborate design and part combination makes product with fresh appearance and its precision meets or overpass the same product all over the world. Excellent circuit design takes multiple protection functions into consideration. It is a card reading equipment that can read or write many types of cards, supporting 4 pieces SIM card operation.
Specification:
| Card Type | IC card: ISO7816-1、2、3、4 standard Support T=0,T=1 CPU Card Support T=0,T=1 PSAM Card Contactless card: ISO/IEC 14443 Type A & Type B Support Mifare 1 S50,S70, UL card, Mifare Plus, Mifare Desfire Magnetic card: ISO7810, ISO7811 -(1-6), ISO7812, ISO7813 And ISO15457 |
| Card Specification | Material: Paper card and PC card Width: 54 ± 0.5 mm(W) Length: 85 ± 0.5 mm Thickness: 0.76 ～0.9 mm |
| Power Supply | DC24V |
| Operation Current | Idle:<200mA Peak:<3000mA |
| Interface | RS232 |
| Environmental Conditions | Operation Temp: 0℃ to 50℃ Operation Humi: 20～80% (Relative Humidity) |
| Life Time | Drive parts: 500,000cycles Magnetic head: 800,000cycles IC card contact: 300,000cycles |
| Certified | EMV & PBOC |
| Weight | About 0.8kg |
