Features:
- Ultra-thin body design, dedicated to highly integrated terminal service equipment
- Maximized paper bin design, 80*80 large paper roll, avoid frequent paper changes
- Diverse ways to open the cover: button, key and electronic lock
- Front maintenance, no need to open the cabinet to change paper
- Divided into framed and frameless, frameless is easier to embed in terminal service equipment
- Power supply is DC24V /2A
- Full cut / partial cut , Cut life is 1000,000 cuts
- Compatible with Windows 7/8/10/Linux,freely provide SDK/Driver
Specifications:
| Printing Method | Thermal Line |
| Resolution | 8 dots/mm (203 dpi), 576 dots/line |
| Printing Speed | 170 mm/s (Max) |
| Effective Printing Width | 72 mm |
| TPH | 100km |
| Paper Width | 80mm/58mm |
| Paper Type | Normal Thermal Paper/ Blackmark Paper |
| Paper Size | Max 80 mm×Ø80mm |
| Paper Thickness | 0.06mm～0.12mm |
| Paper Supply Method | Drop-in easy paper loading |
| Print Font | ASCII 12 x24; Chinese: 24 x 24 |
| Barcode | 1D: UPC-A、UPC-E、EAN-13、EAN-8、CODE39、ITF25、CODABAR、 CODE93、CODE128 |
| 2 D: PDF417、QRCODE、Data Matrix | |
| Interface | Serial RS232 / USB |
| Power supply | DC24V±10%, 2A |
| Weight | 780 (Exculde Paper Roll) |
| Operating Temp/Humidity | -10～50℃ / 20～85% |
| Storage Temp/Humidity | -20～60℃ / 10～90% |
| Outer Line Dimension | 92.03mm*140mm*186.32mm (L*W*D) |
| Sensors | Blackmark sensor,paper end,paper near end |
Applications:
- Medical self-service terminal
- Self-service queuing terminal
- Self-service catering terminal
- Unmanned self-service cash register
