Features:
- Kiosk mounted thermal printer
- Printing speed:130mm/s(24V) fast printing
- Fashionable, delicate and elegant
- Low noise direct thermal printing method
- Various image/curves/characters printing function
- Paper out detection, automatic memory printing function
- Serial/USB interface
- Power supply DC9-24V
- Compatible with Windows 7/8/10/Linux,freely provide SDK/Driver
Applications:
- Self-service vending machine
- Self-service cash register
- Queuing machine
- Advertisement machine
- Gaming machine
- Medical equipment
- Industrial instruments & meters
Specifications:
| Print Method | Thermal line |
| Resolution | 8 dots/mm, 384 dots/line |
| Effective Printing Width | 48mm |
| Character Set | ASCII, GB18030(Chinese), BIG5 (24*24) |
| Print Font | Codepage,ASCII 9*24,12*24 |
| Print Speed | 12V: 100mm/s 24V:130mm/s |
| Self-defined Character | Yes |
| Barcode | UPC-A, UPC-E, EAN-13, EAN-8,CODE39,
ITF25 ,CODABAR, CODE93, CODE128,QR Code, PDF417 |
| Graphic | Support bitmap downloading |
| Sensor | Paper end sensor,Paper near end sensor |
| Overheating Protection | Yes |
| Interface | RS-232+USB |
| Power Supply | DC9~24/2A,Recommend 12V-24V 2A |
| TPH Life | 50km |
| Cutter life | 1,000,000 cuts |
| Paper Type | Thermal paper |
| Paper Width | 57.5± 0.5mm |
| Paper Thickness | 0.055 to 0.09mm |
| Paper Roll Diameter | Max: 50.0mm |
| Paper Supply Method | Drop-in Easy Loading |
| Paper Cutting Method | Full / Partial cut |
| Operating Temp/Humidity | 0-50°C/10%-80% |
| Storage Temp/Humidity | -20-60°C / 10%-90% |
| Installation Port Size(LxWxH) | 96.7*95.7*52.7mm(W*H*D) |
| Outline Dimension (LxWxH) | 100.3*99.9*60mm(W*H*D) |
| Command | ESC/POS |
| Colour | Black/ white |
| Driver | Windows/Linux |
| SDK | Windows/Android/IOS |
