80mm bluetooth thermal printer Features:
1. Support various of intelligent terminal , PDA printing
2. Support one dimensional code, QR code, image, curves printing
3. Water proof, dust proof IP54 ( can work even in heavy rainstorm weather)
4. Resist fall 2.0 concrete
5. CCC, CE, FCC certificate
6. Fast charging, finish charging in 3 hours. Support dual charging( adaptor fast charging, USB slow charging to meet client’s demand of using while charging)
7. Compatible for black mark paper, gap label, sucessive paper
8. Support button function
80mm bluetooth thermal printer Specifications:
| Interfaces | USB (Type C)+Bluetooth |
| Print Comand | TSPL /ESC/POS |
| Print Method | Direct Line Thermal |
| Print Speed | 60mm/s |
| Print Resolution | 203dpi |
| TPH Life | 50km (25% printing density or less) or per dot: 100 million pulses |
| Memory | ROM: 8192KB / DRAM: 8192KB |
| Inner Code | ASCII font library (8×16, 12×24, 16×32, 24×48), GBK (16×16), GB1830 (24X24) |
| Print content | English, Numbers, Various symbols, Chinese characters, Graphics, Curves, Pre-stored icons |
| One-dimensional code | UPC / UPC-E / CODE39 / EAN-13 / EAN-8 / CODABAR / CODE128 / CODE93 / CODE128 / ITF |
| Two-dimensional code | QR Code, PDF417 |
| Parameter settings | Printing parameters, Bluetooth parameters, other parameters, etc |
| Black mark detection | YES |
| Label detection | YES |
| Status indication TFT display | Communication mode, Printing, Out of paper, Out of power, Sleep mode, Paper type |
| Alarm function | Paper out detection, Low battery detection |
| Paper | |
| Thermal Paper Types | continuous paper, label paper |
| Available Rang of Paper Width | 20-80mm |
| Roll Diameter | φ≤50mm |
| Available Printing Width | 72mm (24 Chinese characters/line 48 English characters/line standard 24 dot matrix high font) |
| Paper Thickness | 0.06-0.20 mm |
| Electrical | |
| Power Supply | AC 100-240v 50\60Hz 0.4A DC 5V 1A |
| Li-Battery | DC7.4V/ 2600 mAh rechargeable lithium battery |
| Package | |
| Printer Dimension | 115*110*58mm |
| Unit Weight | 350g （with battery) |
| Pieces Per CTN | 40 Pieces |
